3M™ 051128-60332 Premium Grade Electric Arc Proofing Tape, 20 ft L x 1-1/2 in W, 30 mil THK, Intumescent Elastomer Backing, Black

Selected 3M™ 051128-60332 Premium Grade Electric Arc Proofing Tape, 20 ft L x 1-1/2 in W, 30 mil THK, Intumescent Elastomer Backing, Black
3M™ 051128-60332 Premium Grade Electric Arc Proofing Tape, 20 ft L x 1-1/2 in W, 30 mil THK, Intumescent Elastomer Backing, Black

Short Description

Scotch® fire-retardant electric arc proofing tape 77 is designed to protect most types of electrical cables when exposed to potential failures in an adjacent cable. Its specially formulated adhesive expands in fire to form a thick char build-up between the flame and the cable. The resulting firewall acts as a heat shield and flame barrier, thus protecting the nearby cables and accessories.

Specification

Length
20 ft
Maximum Operating Temperature
73 deg F
Backing Material
Intumescent Elastomer
Color
Black
Specifications Met
ASTM D1000, ASTM D2863, ASTM C-518
Standard & Approvals
ARRA Compliant, Buy American Act Compliant, RoHS Compliant
Tensile Strength
1200 psi
Thickness
30 mil
