3M™ MC2/0-12RX Non-Insulated Large Gauge Corrosion-Resistant Compression Lug Terminal, 2/0 AWG Copper Conductor, Die Code: 1/2 in, 1/2 in Stud, ETP Copper

Selected 71000114353M™ MC2/0-12RX Non-Insulated Large Gauge Corrosion-Resistant Compression Lug Terminal, 2/0 AWG Copper Conductor, Die Code: 1/2 in, 1/2 in Stud, ETP Copper
71000114353M™ MC2/0-12RX Non-Insulated Large Gauge Corrosion-Resistant Compression Lug Terminal, 2/0 AWG Copper Conductor, Die Code: 1/2 in, 1/2 in Stud, ETP Copper

Documents

Short Description

3M™ Scotchlok™ compression lug ring tongue terminal has a non insulated, seamless barrel and ensures an ideal fit while offering reliable and safe performance. copper construction offers good conductivity and a tin plated finish resists corrosion.

Features

  • Compression lugs are non insulated and seamless
  • The tool used compresses the lug from all sides
  • Crimp connection

Specification

Voltage Rating
600 VAC
Color
Black
Conductor Type
Copper
Standard & Approvals
UL Listed
Tongue Type
Ring
Conductor Size
2/0 AWG
Barrel Type
Non-Insulated/Seamless
Dimensions
2.05 in L x 0.83 in W x 0.1 in THK
Barrel Size
0.46 in ID
Die Code
1/2 in
Material
ETP Copper
Stud Size
1/2 in
Temperature Rating
347 deg F
