3M™ MC2-516RX Large Gauge Ring Tongue Terminal, 2 AWG Non-Insulated Wire, ETP Copper

Selected 71000360303M™ MC2-516RX Large Gauge Ring Tongue Terminal, 2 AWG Non-Insulated Wire, ETP Copper
71000360303M™ MC2-516RX Large Gauge Ring Tongue Terminal, 2 AWG Non-Insulated Wire, ETP Copper

Documents

Short Description

3M™ Scotchlok™ compression lug ring tongue terminal has a non insulated, seamless barrel and ensures an ideal fit while offering reliable and safe performance. copper construction offers good conductivity and a tin plated finish resists corrosion.

Features

  • Compression lugs are non insulated and seamless
  • The tool used compresses the lug from all sides
  • Crimp connection

Specification

Voltage Rating
600 VAC
Color
Brown
Standard & Approvals
UL Listed
Temperature Rating
347 deg F
Specifications
5/16 in Stud
Barrel Type
0.34 in ID Seamless
Dimensions
1.69 in L x 0.65 in W x 0.1 in THK
Material
ETP Copper
