Allen-Bradley 100-C09D01 Contactor, 9 A, IEC, 110V 50 Hz / 120V 60 Hz., AC, 3 Normally Open poles, 0 NO Contacts & 1 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
Allen-Bradley 100-C09D01 Contactor, 9 A, IEC, 110V 50 Hz / 120V 60 Hz., AC, 3 Normally Open poles, 0 NO Contacts & 1 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
SKU: A-B100C09D01
Manufacturer Part Number: 100-C09D01
UPC: 662072609514
Documents
Specification
| Minimum Order Qty | 1 |
|---|---|
| Order Interval | 1 |
| 1-Phase HP (60 Hz) 115V Rating | 0.5 |
| 1-Phase HP (60 Hz) 230V Rating | 1.5 |
| 3-Phase HP (60 Hz) 200V Rating | 2 |
| 3-Phase HP (60 Hz) 230V Rating | 2 |
| 3-Phase HP (60 Hz) 460V Rating | 5 |
| 3-Phase HP (60 Hz) 575V Rating | 7.5 |
| 3-Phase kW (50 Hz) 230V Rating | 3 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 4 |
| 3-Phase kW (50 Hz) 500V Rating | 4 |
| 3-Phase kW (50 Hz) 690V Rating | 4 |
| Catalog ID | A-B100C09D01 |
| Coil Termination | Line Side |
| Coil Voltage | 110V 50Hz / 120V 60Hz |
| Contact Configuration | 0 N.O. 1 N.C. Auxiliary Contact Configuration |
| Package Quantity | 1 |
| Rated Operating Current, AC-3 | 9A |
| Connection | Screw Terminals |
