Allen-Bradley 100-C09EJ300 100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 9A, 3 N.O. 1 N.C. Main Contact Configuration
Allen-Bradley 100-C09EJ300 100-C IEC Contactor, 24V DC Electronic Coil, Screw Terminals, Line Side, 9A, 3 N.O. 1 N.C. Main Contact Configuration
SKU: A-B100C09EJ300
Manufacturer Part Number: 100-C09EJ300
UPC: 662074889150
Specification
| Minimum Order Qty | 1 |
|---|---|
| Order Interval | 1 |
| 1-Phase HP (60 Hz) 230V Rating | 1.5 |
| 3-Phase HP (60 Hz) 200V Rating | 2 |
| 3-Phase HP (60 Hz) 230V Rating | 2 |
| Coil Termination | Line Side |
| Package Quantity | 1 |
| 3-Phase HP (60 Hz) 460V Rating | 5 |
| 3-Phase kW (50 Hz) 690V Rating | 4 |
| 3-Phase kW (50 Hz) 500V Rating | 4 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 4 |
| 3-Phase kW (50 Hz) 230V Rating | 3 |
| Rated Operating Current, AC-3 | 9A |
| Contact Configuration | 3 N.O. 1 N.C. Main Contact Configuration |
| Coil Voltage | 24V DC Electronic Coil w/ Elec. Interface |
| Catalog ID | A-B100C09EJ300 |
| 3-Phase HP (60 Hz) 575V Rating | 7.5 |
| Number Of Poles | 4 Poles |
| Connection | Screw Terminals |
