Allen-Bradley 100-C16EJ300 Contactor, 16 A, IEC, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 NO poles & 1 NC Pole, 24V DC Electronic, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
Allen-Bradley 100-C16EJ300 Contactor, 16 A, IEC, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 NO poles & 1 NC Pole, 24V DC Electronic, No Contact Configuration, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
SKU: A-B100C16EJ300
Manufacturer Part Number: 100-C16EJ300
UPC: 662074889211
Documents
Specification
| No of Poles | 4 Poles |
|---|---|
| Package Quantity | 1 |
| Rated Operating Current, AC-3 | 16A |
| 1-Phase HP (60 Hz) 115V Rating | 1 |
| 1-Phase HP (60 Hz) 230V Rating | 3 |
| 3-Phase HP (60 Hz) 200V Rating | 5 |
| 3-Phase HP (60 Hz) 230V Rating | 5 |
| 3-Phase HP (60 Hz) 460V Rating | 10 |
| 3-Phase HP (60 Hz) 575V Rating | 15 |
| 3-Phase kW (50 Hz) 230V Rating | 5.5 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 7.5 |
| 3-Phase kW (50 Hz) 500V Rating | 7.5 |
| 3-Phase kW (50 Hz) 690V Rating | 7.5 |
| Coil Termination | Line Side |
| Connection | Screw Terminals |
| Contact Configuration | 3 N.O. 1 N.C. Main Contact Configuration |
| Coil Voltage | 24V DC Electronic Coil w/ Elec. Interface |
