Allen-Bradley 100-C30KJ10 Contactor, 30 A, IEC, 24V 50/60 Hz, AC, 3 Normally Open poles, 24V AC 50/60 Hz, 1 NO Contacts & 0 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
Allen-Bradley 100-C30KJ10 Contactor, 30 A, IEC, 24V 50/60 Hz, AC, 3 Normally Open poles, 24V AC 50/60 Hz, 1 NO Contacts & 0 NC Contacts, Single Pack, Line Side Coil Termination, Screw Terminals, Motor Load
SKU: A-B100C30KJ10
Manufacturer Part Number: 100-C30KJ10
UPC: 662468716017
Documents
Specification
| Minimum Order Qty | 1 |
|---|---|
| Order Interval | 1 |
| 3-Phase kW (50 Hz) 230V Rating | 10 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 15 |
| 3-Phase kW (50 Hz) 500V Rating | 15 |
| 3-Phase kW (50 Hz) 690V Rating | 15 |
| Coil Termination | Line Side |
| Contact Configuration | 1 N.O. 0 N.C. Auxiliary Contact Configuration |
| Package Quantity | 1 |
| Rated Operating Current, AC-3 | 30A |
| 3-Phase HP (60 Hz) 575V Rating | 25 |
| 3-Phase HP (60 Hz) 460V Rating | 20 |
| 3-Phase HP (60 Hz) 230V Rating | 10 |
| 3-Phase HP (60 Hz) 200V Rating | 7.5 |
| 1-Phase HP (60 Hz) 230V Rating | 5 |
| 1-Phase HP (60 Hz) 115V Rating | 2 |
| No of Poles | 3 Poles |
| Catalog ID | A-B100C30KJ10 |
| Connection | Screw Terminals |
| Coil Voltage | 24V 50/60Hz |
