Allen-Bradley 100S-C30EJ14BC Safety Contactor, 30 A, 24V50/60Hz/24VDC Elec Cl, 3 Normally Open Power poles, 24V DC Electronic, 1 NOC & 4 NCC, Line Side Coil Termination, Bifuracated Contact

Selected Allen-Bradley 100S-C30EJ14BC Safety Contactor, 30 A, 24V50/60Hz/24VDC Elec Cl, 3 Normally Open Power poles, 24V DC Electronic, 1 NOC & 4 NCC, Line Side Coil Termination, Bifuracated Contact
Allen-Bradley 100S-C30EJ14BC Safety Contactor, 30 A, 24V50/60Hz/24VDC Elec Cl, 3 Normally Open Power poles, 24V DC Electronic, 1 NOC & 4 NCC, Line Side Coil Termination, Bifuracated Contact

Documents

Specification

No. of Power Poles
3 N.O.
Rated Operating Current, AC-3
30A
1-Phase HP (60 Hz) 115V Rating
2
1-Phase HP (60 Hz) 230V Rating
5
3-Phase HP (60 Hz) 200V Rating
7.5
3-Phase HP (60 Hz) 230V Rating
10
3-Phase HP (60 Hz) 460V Rating
20
3-Phase HP (60 Hz) 575V Rating
25
3-Phase kW (50 Hz) 230V Rating
10
3-Phase kW (50 Hz) 400V/415V Rating
15
3-Phase kW (50 Hz) 500V Rating
15
3-Phase kW (50 Hz) 690V Rating
15
Coil Termination
Line Side
Coil Voltage
24V DC Electronic Coil w/ Elec. Interface
Contact Configuration
1 N.O. 4 N.C.
Special Features
Bifurcated Contact
