Allen-Bradley 104-C30L22 104-C Reversing Contactors, 30A, Line Side, 200-220V 50Hz / 208-240V 60Hz, 1 N.O. 1 N.C.
Allen-Bradley 104-C30L22 104-C Reversing Contactors, 30A, Line Side, 200-220V 50Hz / 208-240V 60Hz, 1 N.O. 1 N.C.
SKU: A-B104C30L22
Manufacturer Part Number: 104-C30L22
UPC: 611320332537
Documents
Specification
| Rated Operating Current, AC-3 | 30A |
|---|---|
| Terminal Type | Screw Terminals |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| 1-Phase HP (60 Hz) 115V Rating | 2 |
| 1-Phase HP (60 Hz) 230V Rating | 5 |
| 3-Phase HP (60 Hz) 200V Rating | 7.5 |
| 3-Phase HP (60 Hz) 230V Rating | 10 |
| 3-Phase HP (60 Hz) 460V Rating | 20 |
| 3-Phase HP (60 Hz) 575V Rating | 25 |
| 3-Phase kW (50 Hz) 230V Rating | 10 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 15 |
| 3-Phase kW (50 Hz) 500V Rating | 15 |
| 3-Phase kW (50 Hz) 690V Rating | 15 |
| Auxiliary Contact Configuration | 1 N.O. 1 N.C. |
| Catalog ID | A-B104C30L22 |
| Coil Code | 200-220V 50Hz / 208-240V 60Hz |
| Coil Termination | Line Side |
