Allen-Bradley 109-C09VKFE1C-1 109C IEC Enclosed Non-reversing Non-Combination Starter, 100-C09, IP66 (EN/IEC Only) ABS Plastic - Small (Indoor Use Only), 230V 50/60Hz, E1 Plus OLR 1.00 - 5.00A

Selected 109-C09VKFE1C-1Allen-Bradley 109-C09VKFE1C-1 109C IEC Enclosed Non-reversing Non-Combination Starter, 100-C09, IP66 (EN/IEC Only) ABS Plastic - Small (Indoor Use Only), 230V 50/60Hz, E1 Plus OLR 1.00 - 5.00A
109-C09VKFE1C-1Allen-Bradley 109-C09VKFE1C-1 109C IEC Enclosed Non-reversing Non-Combination Starter, 100-C09, IP66 (EN/IEC Only) ABS Plastic - Small (Indoor Use Only), 230V 50/60Hz, E1 Plus OLR 1.00 - 5.00A

Specification

Minimum Order Qty
1
Order Interval
1
Amperage Rating
100-C09 (9 Amps)
Catalog ID
A-B109C09VKFE1C1
Coil Voltage
230V 50/60Hz
Enclosure
IP66 (EN/IEC Only) ABS Plastic - Small (Indoor Use Only)
Phases
Three Phase
Max. kW, (380/415V)Three-Phase
4
Max. Hp, (575V) Three-Phase
7.5
Max. Hp, (460V) Three-Phase
5
Max. Hp, (230V) Three-Phase
2
Max. Hp, (230V) Single-Phase
1.5
Max. Hp, (200V) Three-Phase
2
Max. Hp, (115V) Single-Phase
0.5
Full Load Current Range (A)
1.00 - 5.00A
Overload Relay Type
Adjustable Trip Class 10...30, Automatic/Manual Reset
