Allen-Bradley 140G-G3C3-C25 140G - Molded Case Circuit Breaker, G frame, 35 kA Interrupt Rating, T/M - Thermal Magnetic, 3 Poles, Rated Current 25 A
Allen-Bradley 140G-G3C3-C25 140G - Molded Case Circuit Breaker, G frame, 35 kA Interrupt Rating, T/M - Thermal Magnetic, 3 Poles, Rated Current 25 A
SKU: A-B140GG3C3C25
Manufacturer Part Number: 140G-G3C3-C25
UPC: 885630446639
Documents
Specification
| Interrupting Rating, 50/60 Hz, 480V (kA) | 35 |
|---|---|
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Breaking Capacity, 50/60 Hz, 220V (kA) | 85 |
| Breaking Capacity, 50/60 Hz, 415V (kA) | 50 |
| Breaking Capacity, 50/60 Hz, 440V (kA) | 50 |
| Interrupting Rating, 50/60 Hz, 240V (kA) | 65 |
| Frame/Rating | G Frame (125 A) |
| Interrupting Rating, 50/60 Hz, 600V (kA) | 14 |
| Number Of Poles | 3 Poles |
| Protection | T/M - Thermal Magnetic |
| Breaking Capacity, 50/60 Hz, 690V (kA) | 8 |
| Catalog ID | A-B140GG3C3C25 |
| Device Type | 140G - Molded Case Circuit Breaker |
