Allen-Bradley 140G-I3C3-D12 140G - Molded Case Circuit Breaker, I frame, 35 kA, T/M - Thermal Magnetic, 3 Poles, Rated Current 125 A
Allen-Bradley 140G-I3C3-D12 140G - Molded Case Circuit Breaker, I frame, 35 kA, T/M - Thermal Magnetic, 3 Poles, Rated Current 125 A
SKU: A-B140GI3C3D12
Manufacturer Part Number: 140G-I3C3-D12
UPC: 885630444574
Specification
| Frame/Rating | I Frame (225 A) |
|---|---|
| Interrupting Rating, 50/60 Hz, 240V (kA) | 65 |
| Interrupting Rating, 50/60 Hz, 480V (kA) | 35 |
| Interrupting Rating, 50/60 Hz, 600V (kA) | 10 |
| Number Of Poles | 3 Poles |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Breaking Capacity, 50/60 Hz, 220V (kA) | 85 |
| Breaking Capacity, 50/60 Hz, 415V (kA) | 50 |
| Breaking Capacity, 50/60 Hz, 690V (kA) | 6 |
| Protection | T/M - Thermal Magnetic |
| Device Type | 140G - Molded Case Circuit Breaker |
| Catalog ID | A-B140GI3C3D12 |
| Breaking Capacity, 50/60 Hz, 440V (kA) | 40 |
