Allen-Bradley 140G-J6F3-D10 140G - Molded Case Circuit Breaker, J frame, 65 kA Interrupt Rating, T/M - Thermal Magnetic, 3 Poles, Rated Current 100 A
Allen-Bradley 140G-J6F3-D10 140G - Molded Case Circuit Breaker, J frame, 65 kA Interrupt Rating, T/M - Thermal Magnetic, 3 Poles, Rated Current 100 A
SKU: A-B140GJ6F3D10
Manufacturer Part Number: 140G-J6F3-D10
UPC: 887172307645
Documents
Specification
| Interrupting Rating, 50/60 Hz, 480V (kA) | 65 |
|---|---|
| Interrupting Rating, 50/60 Hz, 600V (kA) | 25 |
| Number Of Poles | 3 Poles |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Protection | T/M - Thermal Magnetic |
| Breaking Capacity, 50/60 Hz, 690V (kA) | 15 |
| Breaking Capacity, 50/60 Hz, 440V (kA) | 65 |
| Breaking Capacity, 50/60 Hz, 415V (kA) | 70 |
| Breaking Capacity, 50/60 Hz, 220V (kA) | 100 |
| Interrupting Rating, 50/60 Hz, 240V (kA) | 150 |
| Frame/Rating | J Frame (250 A) |
| Device Type | 140G - Molded Case Circuit Breaker |
| Catalog ID | A-B140GJ6F3D10 |
