Allen-Bradley 1769-IF16V 16 Channel Compact High- density Analog Voltage Input Module

Selected 1769-IF16VAllen-Bradley 1769-IF16V 16 Channel Compact High- density Analog Voltage Input Module
1769-IF16VAllen-Bradley 1769-IF16V 16 Channel Compact High- density Analog Voltage Input Module

Specification

Mounting
DIN Rail / Panel Mount
Number of Channels
16
Type
Analog Input Module
Display
Status LEDs
Enclosure
None (open-style)
Sub Brand
CompactLogix
Special Features
Voltage only, 16 bits resolution
Height
118mm, 4.65"
Input Signal
±10V, 0...10V, 0...5V, 1...5V
Isolation
500V AC or 710V DC for 1 min (qualification test), output group to bus. 30V AC/30V DC working voltage (IEC Class 2 reinforced insulation)
Depth
87mm, 3.43"
Width
35mm, 1.38"
