Bussmann® FWX-100A North American Style High Speed Fuse, 100 A, 250 VAC/VDC, 20/200 kA, Cartridge Body
Bussmann® FWX-100A North American Style High Speed Fuse, 100 A, 250 VAC/VDC, 20/200 kA, Cartridge Body
SKU: BUSFWX-100A
Manufacturer Part Number: FWX-100A
UPC: 051712150637
Features
- Low arc voltage and low energy let-through
- Excellent DC performance
- Low watts loss
- Superior cycling capability
- North American style bolted tags and flush end high speed fuses
Specification
| Interrupt Rating | 20/200 |
|---|---|
| Material | Ceramic |
| Mounting Type | Bolt-In/Flush/Stud |
| Amperage Rating | 100 A |
| Voltage Rating | 250 V |
| Application | For DC common bus, DC drives, power converters/rectifiers and reduced voltage starters |
| Body Size | 1.22 in Dia x 3.13 in L |
| Body Type | Cartridge |
| Element | Single |
| Indicating/Non-Indicating | Non-Indicating |
| Rejection/Non-Rejection | Non-Rejection |
| Standard & Approvals | ARRA Compliant, Buy American Act Compliant, RoHS 2011/65/EU, UL Recognized to Guide No. JFHR2, File No. E56412, CSA Class 1422-30, File No. 53787, CE Certified |
| Terminal Type | Blade |
