Color-Keyed® 54509 Two-Way Splice Connector, 1/0 AWG Conductor, 1.63 in L, Standard Barrel, Wrought Copper, Pink

Selected 54518Color-Keyed® 54507 2-Way Standard Barrel Splice Connector, 2 AWG Copper Conductor, Die Code: 33, 1-1/4 in L, Copper
54518Color-Keyed® 54507 2-Way Standard Barrel Splice Connector, 2 AWG Copper Conductor, Die Code: 33, 1-1/4 in L, Copper

Documents

Short Description

Color-Keyed® compression system ensures a proper crimp onto the conductor by matching the right connector to the right tool and die, using a color coding system that was developed and introduced to the industry by Thomas & Betts.

Features

  • Two-way high conductivity connectors provide high pullout values
  • Easy to insulate and provide a low-resistance connection of high quality and low installed cost
  • Color coded for correct matching of installing die and connector
  • 35 Kv max voltage
  • 42 die code
  • 225/24 = 90.8 kcmil, NO 1 Weld, 133/.0254 wire size flex
  • 10/Pack, 100/pack

Specification

Length
1.63 in
Material
Wrought Copper
Minimum Order Qty
1
Order Interval
1
Barrel Type
Standard
Catalog ID
T-B54509
Color
Pink
Conductor Size
1/0 AWG
Conductor Type
Copper
Dimensions
0.52 in Dia
Finish
Electro Tin Plated
Type
Two-Way
Voltage Rating
600 VAC
Standard & Approvals
CSA Certified, RoHS Complaint, UL Listed
