EATON A201K2BA Full Voltage Non-Reversing NEMA Contactor, 110/120 VAC V Coil, 45 A, 1NO Contact, 2 Poles

Selected EATON A201K2BA Full Voltage Non-Reversing NEMA Contactor, 110/120 VAC V Coil, 45 A, 1NO Contact, 2 Poles
EATON A201K2BA Full Voltage Non-Reversing NEMA Contactor, 110/120 VAC V Coil, 45 A, 1NO Contact, 2 Poles

Features

  • 3 hp at 115 VAC, 7-1/2 hp at 230 VAC 1PH, 10 hp at 208 VAC, 15 hp at 240 VAC, 25 hp at 480 VAC, 25 hp at 600 VAC 3PH UL horsepower
  • Full voltage non-reversing operation
  • Eaton selling policy 25000, 1 year from the date of installation of the product or 18 months from the date of shipment of the product, whichever occurs first
  • Front connected contactor

Specification

Standard & Approvals
UL Listed, CSA Certified
Coil Voltage
120/110 VAC
Enclosure Type
Open
Frequency Rating
50/60 Hz
Maximum Load Current
45 A
Number Of Poles
2
Type
Non-Reversing
Size
SZ 2
Dimensions
4.94 in L x 4.38 in W x 3.31 in H
Series
A200
