EATON C25BNB240A Compact Definite Purpose Contactor With Metal Mounting Plate, 110/120 VAC V Coil, 40/50 A, 2 Poles

Selected C25BNB240AEATON C25BNB240A Compact Definite Purpose Contactor With Metal Mounting Plate, 110/120 VAC V Coil, 40/50 A, 2 Poles
C25BNB240AEATON C25BNB240A Compact Definite Purpose Contactor With Metal Mounting Plate, 110/120 VAC V Coil, 40/50 A, 2 Poles

Documents

Short Description

Eaton offers the most complete line of Definite purpose (DP) contactors in the industry. Designed for heating, ventilation, air conditioning and refrigeration (HVACR) applications, Eaton's DP contactors are designed to handle the most challenging installations.

Features

  • Compact, two-pole frame
  • Contactor, open model
  • Binding head screw and quick connect terminals (side-by-side)
  • Completely encased design impervious to dust and other environmental elements
  • Contactors and starters (up to 60 A)
  • Open components and enclosed designs
  • Open with metal mounting plate

Specification

Frequency Rating
50/60 Hz
Maximum Load Current
40 A
Number Of Poles
2
Minimum Order Qty
1
Order Interval
1
Coil Voltage
110 to 120 VAC
Enclosure Type
Open
Application
For refrigeration, air conditioning and resistance heating to traditional standards for quality and reliability
Standard & Approvals
UL Listed, CSA Certified
Type
Non-Reversing
Terminal
Binding Head Screw/Quick Connect
Dimensions
3.19 in L x 2.32 in W x 1.97 in H
Catalog ID
C-HC25BNB240A
