EATON CHQ140 Type CHQ Classified Replacement Thermal Magnetic Circuit Breaker, 120/240 VAC, 40 A, 10 kAIC Interrupt, 1 Poles
EATON CHQ140 Type CHQ Classified Replacement Thermal Magnetic Circuit Breaker, 120/240 VAC, 40 A, 10 kAIC Interrupt, 1 Poles
SKU: C-HCHQ140
Manufacturer Part Number: CHQ140
UPC: 782113010861
Features
- Type CHQ and 1 in type CL, single and two-pole configurations
- These breakers are classified as direct replacements by underwriters laboratories
- Replacement for square D type QO breakers
- Requires one 3/4 in spaces
Specification
| Interrupt Rating | 10 kA |
|---|---|
| Number Of Poles | 1 |
| Temperature Rating | 60 to 75 deg C |
| Type | Type CHQ |
| Voltage Rating | 120/240 VAC |
| Wire Size | (1) 14 to 8/(2) 14 to 10 AWG |
| Application | For use with Type CH loadcenters |
| Standard & Approvals | UL 489 |
| Amperage Rating | 40 A |
| Dimensions | 2.5 in L x 0.8 in W x 3 in H |
