EATON FD2025 C Series Type FD Molded Case Circuit Breaker, 600 VAC/250 VDC, 25 A, 65 kAIC at 240 VAC/35 kAIC at 480 VAC Interrupt, 2 Poles, Fixed Thermal/Fixed Magnetic Trip

Selected C HFD2025
C HFD2025

Documents

Short Description

EATON's series C molded case circuit breakers are used in panel board, switchboard, motor control center and busway applications for dependable branch circuit protection. They have proven user acceptance for over 20 years and meet or exceed North American standards. Available for systems up to 600 VAC or 250 VDC with current ratings up to 2500 A.

Features

  • Patented contact design features high speed blow open action, resulting in superior performance
  • Suitable for reverse feed applications

Specification

Frame
F
Frequency Rating
50/60
Interrupt Rating
35/65
Number Of Poles
2
Series
C Series
Temperature Rating
40 deg C
Trip Type
Fixed Thermal Magnetic
Type
Type FD
Voltage Rating
600 VAC/250 VDC
Application
Indicating Light, Hazardous Location, Automation and Logic Control Equipment
Standard & Approvals
ARRA, Buy American Act and RoHS Compliant, CE Marked, CSA Certified, UL Listed
Amperage Rating
25 A
Dimensions
3.38 x 2.75 x 6 in
Connection Type
Load
Enclosure Type
NEMA AB1-1993
