EATON PKZM0-6.3 XT Series Manual Motor Protector Circuit Breaker, 690 VAC, 5 A, 50 kA Interrupt, 3 Poles, Class 10 Trip

Selected PKZM0-6.3EATON PKZM0-20 XT Series Manual Motor Protection Circuit Breaker, 690 VAC, 20 A, 3 Poles, Class 10 Trip
PKZM0-6.3EATON PKZM0-20 XT Series Manual Motor Protection Circuit Breaker, 690 VAC, 20 A, 3 Poles, Class 10 Trip

Features

  • Convenient dial adjustment allows the user to select from eight different current levels for precise motor circuit protection
  • High short circuit current ratings can be achieved without the need for fuses or additional limiters, reducing both space and spare parts requirements
  • Motor inrush trip suppressor allows the starting of high efficiency motors without sacrificing sensitive levels of short circuit protection
  • Clears low level faults (the most common type of fault in a motor circuit) more effectively than fuses, preventing faults from cascading and damaging equipment
  • Easily test without having to replace the device (unlike fusible devices) by depressing a push to trip mechanism on the cover

Specification

Standard & Approvals
CE Certified, CSA C22.2 File No. 60947-4-1-14/165628, IEC/EN 60947-4-1, UL 60947-4-1, UL File No. E36332, UL 489
Power Rating
4 kW
Temperature Rating
-25 to 55 deg C
Trip Type
Class 10
Voltage Rating
690 VAC
Actuator Type
Pushbutton
Amperage Rating
5 A
Connection Type
Screw/Spring Loaded
Enclosure Type
IP00/IP20
Frequency Rating
40 to 60 Hz
Interrupt Rating
50 kA
Number Of Poles
3
EANUCC13
4015080727385
Dimensions
1.8 in L x 3 in W x 3.7 in H
Series
XT Series
