Federal Signal StreamLine® SLM100R Low Profile Streamline Modular Multi-Functional Beacon, 120 to 240 VAC, 12 to 24 VAC/VDC, LED Lamp, Surface Mount, Red, CE Marked, UL Listed, cULus Listed

Selected IDW IMAGE 3c0d5446f1660c39dbb6ed406dace2955795e75fed345222c57e705e7960c5ae
IDW IMAGE 3c0d5446f1660c39dbb6ed406dace2955795e75fed345222c57e705e7960c5ae

Documents

Short Description

Model SLM100 offers a multi-functional LED beacon with high optical performance. Developed with a multiple input technology, Model SLM100 allows three separate light effects (steady, flashing or rotating) controllable via independent electric contacts. The steady light option offers a conspicuous and consistent light Signal. The flashing mode consists of a triple flash strobe effect ideal for all applications where an immediate attention gain is mandatory. And the rotating light offers a traditional rotating beacon effect without moving parts, which enhances product life. Model SLM100 body material is a self-extinguishing polycarbonate material with high impact and UV resistance suitable for outdoor applications.

Features

  • PLC compatible with PNP or NPN connections
  • 300 mA at 12 VDC, 150 mA at 24 VDC, 510 mA at 12 VAC, 360 mA at 24 VAC, 100 mA at 120 VAC, 70 mA at 240 VAC
  • Three separate light effects

Specification

Voltage Rating
120 to 240 VAC/12 to 24 VAC/VDC
Color
Red
Type
Low Profile Streamline Modular Multi-Functional
Lamp Type
LED
NEMA Rating
NEMA 4X/IP66
Average Life
50000 hr
Shape
Cylindrical
Series
SLM100
Mounting Type
Surface
Housing Material
Polycarbonate
Flash Rate
85 fpm
Dimensions
3.9 in W x 3.9 in D x 4.23 in H
Flash Type
Flashing/Rotating/Steady
Temperature Rating
-22 to 122 deg F
Specifications Met
CE Marked, UL Listed, cULus Listed
Amperage Rating
70/100/150/300/360/510 mA
