nVent HOFFMAN A51SC Junction Box, 16 in L x 14 in W x 6 in D, NEMA 12, 14 ga Steel
nVent HOFFMAN A51SC Junction Box, 16 in L x 14 in W x 6 in D, NEMA 12, 14 ga Steel
SKU: HOFA1614SC
Manufacturer Part Number: A1614SC
UPC: 783510543907
Features
- Seams continuously welded and ground smooth Bonding provision on cover, oil-resistant gasket
- Weldnuts provided for mounting optional panels and terminal block kits in size 6 x 4 in (152 x 102 mm) and larger
- External welded-on mounting brackets for easy installation
Specification
| Mounting Type | Surface |
|---|---|
| NEMA Rating | NEMA 12 |
| Standard & Approvals | UL 50/50E, Type 12, 13, File No. E27525, cUL Listed per CSA C22.2 No. 94, Type 12, 13, File No. E27525, UL 508A, Type 12, 13, File No. E61997, cUL Listed per CSA C22.2 No. 94, Type 12, 13, File No. E61997, RoHS Complaint |
| Cover Type | Screw |
| Depth | 6 in |
| Finish | Polyester Powder Painted |
| Material | 14 Ga Steel |
| Width | 14 in |
| Series | A51SC |
| Panel Size | 14.75 in L x 12.88 in W |
| Length | 16 in |
| Color | ANSI 61 Gray |
