nVent HOFFMAN A72P60 Enclosure Panel, 56 in W x 68 in H, Steel, White
nVent HOFFMAN A72P60 Enclosure Panel, 56 in W x 68 in H, Steel, White
SKU: HOFA72P60
Manufacturer Part Number: A72P60
UPC: 783510262907
Features
- Steel panels are 12 gauge, finished with white polyester powder paint or a conductive, corrosion resistant coating
- Larger panels have flanges on two or four sides
- Some larger steel panels are 10 gauge and include extra holes for panel lifting
- Panel mounting hardware is furnished with all enclosures which accept these panels
- Painted steel
Specification
| Height | 68 in |
|---|---|
| Material | Steel |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | HOFA72P60 |
| Color | White |
| Finish | Powder Coated |
| Series | PNLFS |
| Suitable For Use With | 72 x 60 in Large NEMA 3R/4/4X/13 Multi-Door Enclosure |
| Width | 56 in |
| Standard & Approvals | RoHS Compliant |
