nVent HOFFMAN A51CH Junction Box, 8 in L x 6 in W x 3-1/2 in D, NEMA 12, 14 ga Steel
nVent HOFFMAN A51CH Junction Box, 8 in L x 6 in W x 3-1/2 in D, NEMA 12, 14 ga Steel
SKU: HOFA806CH
Manufacturer Part Number: A806CH
UPC: 783510554002
Documents
Features
- Oil-resistant gasket
- Seams continuously welded and ground smooth
- Continuous hinge, external screw clamps are quick and easy to operate, bonding provision on door
- External welded-on mounting brackets for easy installation
- NEMA 12, 13
- Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger
Specification
| Mounting Type | Wall |
|---|---|
| NEMA Rating | NEMA 12 |
| Width | 6 in |
| Depth | 3-1/2 in |
| Finish | Polyester Powder Painted |
| Material | 14 Ga Steel |
| Series | A51CH |
| Color | ANSI 61 Gray |
| Standard & Approvals | UL 50/50E, Type 12, 13, File No. E27567, cUL Listed per CSA 22.2 No. 94, Type 12, 13, File No. E27567, UL 508A, Type 12, 13, File No. E61997, cUL Listed per CSA 22.2 No. 94, Type 12, 13, File No. E61997, NEMA/EEMAC Type 12 and 13, CSA, File |
| Application | This easy-to-open, continuous hinge enclosure features screw-down clamps for secure closure and can be used in a wide variety of applications |
| Panel Size | 6.75 in L x 4.88 in W |
| Length | 8 in |
| Cover Type | Continuous Hinge With Clamp |
