nVent HOFFMAN A84N7224FSLP A38 2-Door Large Enclosure With Heavy Duty Handle, 84 in L x 72 in W x 24 in D, NEMA 1/IP30, Steel

Pick Up Only
Selected nVent HOFFMAN A84N7224FSLP A38 2-Door Large Enclosure With Heavy Duty Handle, 84 in L x 72 in W x 24 in D, NEMA 1/IP30, Steel
nVent HOFFMAN A84N7224FSLP A38 2-Door Large Enclosure With Heavy Duty Handle, 84 in L x 72 in W x 24 in D, NEMA 1/IP30, Steel

Features

  • Predrilled holes in lifting base provide bolt-down capability
  • Easily reversible doors on single door models
  • Overlapping doors with no center post on two door models
  • Bonding provision on each door
  • Studs included for mounting optional panels on threaded bolts
  • Optional rack angles mount to top and bottom of front flanges
  • Removable back covers
  • 14 ga steel body and door
  • 12 ga back covers
  • 4 in high 10 ga steel integral lifting base
  • Heights from 48 in to 84 in
  • Sturdy 7 ga lifting tabs

Specification

Length
84 in
Lock
3-Point Latch/Padlock Handle
Material
Steel
Mounting Type
Free Stand
NEMA Rating
NEMA 1/IP30
Minimum Order Qty
1
Order Interval
1
Catalog ID
HOFA84N7224FSLP
Color
Light Gray
Cover Type
Hinged
Depth
24 in
Finish
Polyester Powder Coated
Panel Size
73.16 in H x 68 in W
Series
A38
Type
2-Door Large
Width
72 in
Standard & Approvals
ARRA Compliant, Buy American Act Compliant, RoHS Compliant, PROP65: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
