nVent HOFFMAN A84N7224FSLP A38 2-Door Large Enclosure With Heavy Duty Handle, 84 in L x 72 in W x 24 in D, NEMA 1/IP30, Steel
nVent HOFFMAN A84N7224FSLP A38 2-Door Large Enclosure With Heavy Duty Handle, 84 in L x 72 in W x 24 in D, NEMA 1/IP30, Steel
SKU: HOFA84N7224FSLP
Manufacturer Part Number: A84N7224FSLP
UPC: 783510138868
Features
- Predrilled holes in lifting base provide bolt-down capability
- Easily reversible doors on single door models
- Overlapping doors with no center post on two door models
- Bonding provision on each door
- Studs included for mounting optional panels on threaded bolts
- Optional rack angles mount to top and bottom of front flanges
- Removable back covers
- 14 ga steel body and door
- 12 ga back covers
- 4 in high 10 ga steel integral lifting base
- Heights from 48 in to 84 in
- Sturdy 7 ga lifting tabs
Specification
| Length | 84 in |
|---|---|
| Lock | 3-Point Latch/Padlock Handle |
| Material | Steel |
| Mounting Type | Free Stand |
| NEMA Rating | NEMA 1/IP30 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | HOFA84N7224FSLP |
| Color | Light Gray |
| Cover Type | Hinged |
| Depth | 24 in |
| Finish | Polyester Powder Coated |
| Panel Size | 73.16 in H x 68 in W |
| Series | A38 |
| Type | 2-Door Large |
| Width | 72 in |
| Standard & Approvals | ARRA Compliant, Buy American Act Compliant, RoHS Compliant, PROP65: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
