nVent HOFFMAN HJ1412HWPL2LG Single Door Wall Mount Enclosure, 15.32 in L x 13.3 in W x 6.7 in D, NEMA 4X/IP66
nVent HOFFMAN HJ1412HWPL2LG Single Door Wall Mount Enclosure, 15.32 in L x 13.3 in W x 6.7 in D, NEMA 4X/IP66
SKU: HOFHJ1412HWPL2LG
Manufacturer Part Number: HJ1412HWPL2LG
UPC: 783510158880
Documents
Features
- Enclosures feature a flat, overlapping cover design that ensures a more-secure seal
- Overlapping solid- and window cover models are available
- Latches provide easy access and security
- Compression molded fiberglass construction
- Windows are clear polycarbonate
- Cover fastens with padlockable type 316 stainless steel latches
- Type 304 stainless steel piano hinges
- Integral mounting brackets
- Enclosures protect equipment and operators from indirect electrical contact
- Material is halogen free
Specification
| Lock | Padlock Latch |
|---|---|
| Material | Fiberglass |
| Mounting Type | Wall |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Depth | 6.7 in |
| Standard & Approvals | UL 508A Listed; Type 3, 3R, 4, 4X, 12, 13; File No. E54315, cUL Listed per CSA C22.2 No 94; Type 3, 3R, 4, 4X, 12, 13; File No.E54315 Enclosure flammability per UL 508A, NEMA/EEMAC Type 3, 3R, 4, 4X, 12, 13, CSA File No. 217184: Type 3, 3R, 4, 4X, 12, 13, IEC 60529, RoHS Complaint |
| Width | 13.3 in |
| Type | Single Door |
| Series | HJ/J |
| Panel Size | 12.75 x 10.88 in |
| Cover Type | Flat Hinged |
| Color | Light Gray |
| Catalog ID | HOFHJ1412HWPL2LG |
| NEMA Rating | NEMA 4X/IP66 |
| Length | 15.32 in |
