nVent HOFFMAN ULTRX™ UU606020 1-Door Wall Mount Enclosure, 625 mm L x 612 mm W x 228 mm D, NEMA 4X/IP66, Fiberglass
nVent HOFFMAN ULTRX™ UU606020 1-Door Wall Mount Enclosure, 625 mm L x 612 mm W x 228 mm D, NEMA 4X/IP66, Fiberglass
SKU: HOFUU606020
Manufacturer Part Number: UU606020
UPC: 783510336905
Documents
Features
- Compression molded fiberglass material has excellent temperature and chemical resistance qualities and exhibits outstanding physical properties, including high-impact resistance
- Fiberglass is easily punched, drilled, filed or sawed
- Gasket assures water-tight and dust-tight seal
- Enclosure may be rotated 180 degrees for left and right hinging
- Molded in drip shields are standard with each enclosure
- Impact-resistant polycarbonate window is permanently bonded in place
- Fiberglass mounting brackets and stainless steel attachment screws are provided with each enclosure
- Unique hinge design allows for standard 180 degree door opening with a maximum opening of 270 degrees
- Door hinges are replaceable
- Type 316 stainless steel quarter turn latch. Optional keylocking or padlocking handle available
- Molded in DIN bosses
- Molded bosses on door provide additional mounting provisions
- Integral mounting rails provide infinite panel adjustment front to back
- Optional data pocket is high-impact thermoplastic
- Material is halogen free
- Providing outstanding protection against corrosion and the elements, the clean lines and molded, embossed design of ULTRX fiberglass enclosures make them the most stylish and aesthetically pleasing of their class
- These enclosures feature hidden hinges, a padlocking capability for security, and flexible internal mounting options
- Enclosure flammability evaluated per UL 508
- Solid door
Specification
| Length | 24.61 in |
|---|---|
| Lock | Padlock Latch |
| Material | Fiberglass |
| Mounting Type | Wall |
| NEMA Rating | NEMA 4X/IP66 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Capacity | 4858 cu-in |
| Catalog ID | HOFUU606020 |
| Color | Light Gray |
| Cover Type | Concealed Hinged |
| Depth | 228 mm |
| Finish | Acrylic Enamel Coated |
| Panel Size | 533 x 533 mm |
| Series | ULTRX |
| Type | 1-Door |
| Width | 24.09 in |
| Standard & Approvals | UL 508A, File No. E61997, cUL Listed per CSA C22.2 No. 94, File No. E61997, CSA File No. 42186, IEC 60529, RoHS Complaint |
