ILSCO® ClearChoice® ACO-750 Dual Rated Offset Pigtail Adapter With Insulating Cover, 700 to 750 kcmil Conductor, Die Code: 18, 0.81 in Dia x 1.76 in L Pin, Aluminum
ILSCO® ClearChoice® ACO-750 Dual Rated Offset Pigtail Adapter With Insulating Cover, 700 to 750 kcmil Conductor, Die Code: 18, 0.81 in Dia x 1.76 in L Pin, Aluminum
SKU: ILSACO-750
Manufacturer Part Number: ACO-750
UPC: 783669009644
Features
- Manufactured from high strength aluminum alloy which provides maximum conductivity and excellent crimping characteristics
- Pin is knurled which permits greater surface contact, and off center allows connectors to be rotated for parallel applications. multiple conductorlugs hole spacing does not permit insertion of straight pin connectors, Chamfered barrel which provides easy conductor insertion
- Color-coded end caps inserted in barrel which prevents foreign materials from entering the connector prior to usage and color code identifies the proper compression die
- Prefilled with DE-OX prevents oxides from forming
- stranded class B and C concentric, compressed and unidirectional lay compact
- Rated for full ampacity of incoming conductor
- Clearly marked with conductor size and die index which provides easy identification and tooling recommendation
- Marked with number and location of crimps and color coded
- All supplied with insulating cover which eliminates taping, temperature range is 90 deg C and ensures reliability for aluminum or copper conductors
- Provides easy identification and tooling recommendation
- 3.25 in cover length, 500 kcmil approximate pin size, 2.03 in barrel length, yellow color code, 1-1/32 in ID x 1-15/32 in OD
- 3/Pack
Specification
| Material | Aluminum |
|---|---|
| Series | ACO |
| Stem Diameter | 0.81 in |
| Stem Length | 1.76 in |
| Type | Dual Rated Offset |
| Voltage Rating | 600 VAC |
| Application | For Terminating Connector |
| Standard & Approvals | LR-29601 CSA Certified, RoHS Compliant, UL 486A-B, UL E62525 Listed |
| Conductor Size | 700 kcmil, 750 kcmil |
| Conductor Type | Aluminum/Copper |
| Die Code | 18 |
| Finish | Electro-Tin Plated |
