ILSCO® ClearChoice® CPM-500 Dual Rated Pigtail Adapter With Insulating Cover, 500 kcmil Conductor, Die Code: 16A, 0.681 in Dia x 1-7/8 in L Pin, Aluminum/Copper

Selected CPM-500ILSCO® ClearChoice® CPM-3/0 Dual Rated Pigtail Adapter With Insulating Cover, 3/0 AWG Conductor, Die Code: 12, 0.373 in Dia x 1-3/8 in L Pin, Aluminum/Copper
CPM-500ILSCO® ClearChoice® CPM-3/0 Dual Rated Pigtail Adapter With Insulating Cover, 3/0 AWG Conductor, Die Code: 12, 0.373 in Dia x 1-3/8 in L Pin, Aluminum/Copper

Features

  • Barrel manufactured from high strength aluminum alloy which allows insertion into equipment supplied with either copper or aluminum connectors
  • Pigtail manufactured from high conductivity copper which provides maximum conductivity and excellent crimping characteristics, chamfered barrel which provides easy conductor insertion
  • Color-coded end caps inserted in barrel which prevents foreign materials from entering the connector prior to usage and color code identifies the proper compression die
  • Prefilled with DE-OX prevents oxides from forming
  • stranded class B and C concentric, compressed and unidirectional lay compact
  • Rated for full ampacity of incoming conductor
  • Clearly marked with conductor size and die index which provides easy identification and tooling recommendation
  • Marked with number and location of crimps and color coded
  • All supplied with insulating cover which eliminates taping, temperature range is 90 deg C and ensures reliability for aluminum or copper conductors
  • Provides easy identification and tooling recommendation
  • 2.406 in cover length, 350 approximate pin size, 2.087 in barrel length, pink color code, 55/64 in ID x 1-3/8 in OD
  • 10/Pack

Specification

Minimum Order Qty
1
Order Interval
1
Conductor Type
Aluminum/Copper
Finish
Electro-Tin Plated
Stem Diameter
0.681 in
Stem Length
1-7/8 in
Type
Dual Rated
Voltage Rating
600 VAC
Standard & Approvals
LR-29601 CSA Certified, RoHS Compliant, UL 486A-B, UL E62525 Listed
Series
CPM
Dimensions
3.9625 in W
Die Code
16A
Conductor Size
500 kcmil
Catalog ID
ILSCPM-500
Material
Aluminum-Copper
