Lithonia Lighting® WPX1 LED P2 50K MVOLT DDBXD M4 Architectural Wallpack, (1) LED Lamp, 24 W Fixture, 120 to 277 V, Dark Bronze Housing

Selected WPX1 LED P2 50K MVOLT DDBXD M4Lithonia Lighting® WPX1 LED P2 50K MVOLT DDBXD M4 Architectural Wallpack, (1) LED Lamp, 24 W Fixture, 120 to 277 V, Dark Bronze Housing
WPX1 LED P2 50K MVOLT DDBXD M4Lithonia Lighting® WPX1 LED P2 50K MVOLT DDBXD M4 Architectural Wallpack, (1) LED Lamp, 24 W Fixture, 120 to 277 V, Dark Bronze Housing

Short Description

WPX wall mount luminaires are cost-effective and energy-efficient making them ideal for HID replacement and budget-constrained new construction projects. The WPX family has three sizes with lumen packages of 1500 to 9200 Lumens creating a solution that meets the needs of over-the-door lighting to 400 W metal halide replacement at mounting heights of up to 20 ft. The simple geometric shape of the WPX luminaires allows them to blend with any architecture while the footprint covers the stain left by the fixture it replaces. The WPX features a wide light distribution that creates safe, continuous illumination of the perimeter of the building. Low initial cost, high energy savings and DLC Premium listing enable fast paybacks, typically less than two years. WPX size 1 is available with lumen packages of 1500 (P1) and 3000 (P2) making it ideal for over-the-door applications and mounting heights of up to 10 ft. The WPX1 P2 can replace up to 175 W metal halide while saving 80% energy costs. The WPX1 is available with self-contained emergency battery back-up option to meet Code requirements without the need of a back-box.

Features

    Specification

    Minimum Order Qty
    1
    Order Interval
    1
    Catalog ID
    LITWPX1LEDP250KMVOLTDDBX
    Standard & Approvals
    CSA Certified, DLC Listed, DLC Premium Listed, ECCN EAR99 Certified, UL Listed
    Voltage Rating
    120 to 277 V
    Video
    https://youtu.be/xQ8STwiMmME
    Average Life
    100000 hr
    Ballast Type
    Electronic
    Color Rendering Index (CRI)
    70
    Color Temperature
    5000 K
    Enclosure Type
    IP66
    Fixture Wattage
    24 W
    Housing Finish
    Dark Bronze
    Housing Material
    Die Cast Aluminum
    Lamp Type
    LED
    Lens Type
    Glass
    Light Output
    2954 Lumens/W
    Mounting Type
    Surface
    Number of Lamps
    1
    Lumens
    2900 Lumens
    Type
    Architectural
    Dimensions
    11.1 in W x 3.2 in D x 8.1 in H
    Series
    WPX1
