Mersen A6Y30-1R A6Y Special Purpose Fuse, 30 A, 600 VAC, 500 VDC, 200 kA Interrupt, Class: Form 600
Mersen A6Y30-1R A6Y Special Purpose Fuse, 30 A, 600 VAC, 500 VDC, 200 kA Interrupt, Class: Form 600
SKU: GOUA6Y30-1R
Manufacturer Part Number: A6Y30-1R
EAN: 0782001902223
UPC: 782001902223
Documents
Features
- Mersen Form 600 fuses are the original current-limiting fuses, predating all the standards
- Their 500V DC rating (through 600A) is a useful feature for special fusing applications
- Form 600 fuses provide a high degree of current limitation in AC and DC applications
- Types 1 and 3 are dimensionally interchangeable with Class H and K fuses
- Types 4 and 5 have unique rejection dimensions and are not interchangeable
Specification
| Series | A6Y |
|---|---|
| Terminal Type | Ferrule |
| Type | Special Purpose |
| Voltage Rating | 600 VAC, 500 VDC |
| Application | For special fusing applications |
| Standard & Approvals | UL Recognized Component File E60314, DC Tested to UL248-1 (1-600A. |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Indicating/Non-Indicating | Non-Indicating |
| Amperage Rating | 30 A |
| Body Size | 0.81 in Dia x 5 in L |
| Catalog ID | GOUA6Y30-1R |
| Class | Form 600 |
| Frequency Rating | 50, 60 Hz |
| Interrupt Rating | 200 kA |
| Material | GMG |
| Mounting Type | Clip |
| EANUCC13 | 0782001902223 |
