On-Q® CO1110 Combo Module With RJ31X, F-Type/RJ31X Connection
On-Q® CO1110 Combo Module With RJ31X, F-Type/RJ31X Connection
SKU: P-SCO1110
Manufacturer Part Number: CO1110
UPC: 804428066880
Documents
Features
- 8-way, 1 GHz passive digital HDTV cable splitter
- Coaxial splitter is compatible with existing and future networks such as VoIP and DOCSIS 3.0
- 10-way, 4-line 110 IDC punchdown telecom module
- Includes RJ31X line seizure port for security installations
- The 10 x 8 combo distributes up to 4 incoming telephone lines (110 IDC punchdown) to 10 locations and 1 GHz video to 8 locations
- The innovative mounting bracket includes a detachable platform for the coax splitter, allowing easy access to all termination ports during installation
- The platform attaches securely to create a compact form factor that takes up minimal space in the enclosure
- Surge withstand 6 kV ring wave surge
- 18 ga cold rolled steel material
Specification
| Impedance | 75 Ohm |
|---|---|
| Material | Steel |
| Number of Receptacles | 19 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | P-SCO1110 |
| Color | Black Oxide |
| Connection Type | F-Type/RJ31X |
| Dimensions | 3.1 in L x 6 in W x 5 in H |
| Receptacle Type | (10) IDC/(8) F-Type/(1) RJ31X |
| Temperature Rating | -40 to 60 deg C |
| Standard & Approvals | UL Listed |
| Includes | Mounting Infrastructure |
