Panduit® PV14-10F-E Type PV-F Insulated Fork Terminal, 14 AWG Conductor, 0.92 in L, Brazed Seam/Internal Serration Barrel, Copper, Blue

Selected PV14-610R-CPanduit® PV14-10F-E Type PV-F Insulated Fork Terminal, 14 AWG Conductor, 0.92 in L, Brazed Seam/Internal Serration Barrel, Copper, Blue
PV14-610R-CPanduit® PV14-10F-E Type PV-F Insulated Fork Terminal, 14 AWG Conductor, 0.92 in L, Brazed Seam/Internal Serration Barrel, Copper, Blue

Short Description

Panduit ® Pan-Term ® Terminals are designed and manufactured for fast assembly, and reliable performance. Panduit provides an extensive line of tooling designed specifically to provide optimum performance. As the demand for loose piece terminals increases, it becomes essential to provide a complete system for termination products.

Features

  • Vinyl-insulated
  • Funnel entry barrel configuration
  • Fork design provides for fast and easy installation, without the need to remove fastener
  • Insulation support helps to prevent wire damage in bending applications
  • Brazed-seam protects terminal barrel from splitting during the crimp process
  • Internal barrel serrations assure good wire contact and maximum tensile strength
  • Crimp termination
  • Free hanging (In-line) mounting
  • Recommended tools CT-100A, CT-600-A, CT-1550, CT-1551, CT-2500
  • 20/Bag, Convenience package

Specification

Material
Copper
Type
Insulated
Voltage Rating
600 VAC
Conductor Size
16 to 14 AWG
Barrel Type
Brazed Seam
Color
Blue
Conductor Type
Solid/Stranded Copper
Finish
Tin Plated
Length
0.92 in
Tongue Size
0.34 in W x 0.03 in T
Specifications
7/32 in Wire Strip, 0.17 in Maximum Insulation Dia, 0.24 in Clearance
Standard & Approvals
ABS, C22.2 No. 65 CSA Certified, RoHS Compliant, UL 94V-0 Flammability Rating, UL 486A-486B Listed
Series
PV-F
Tongue Type
Fork
Temperature Rating
221 deg F
Stud Size
NO 10
