Advance OPTANIUM IOP3PSP32SC35I Electronic Fluorescent Ballast, T8 Lamp, 32 W Lamp, 120 to 277 VAC, Programmed/Rapid, 0.88 Ballast Factor

Selected ICN3TTP40SC35IAdvance Centium® ICN3TTP40SC35I Electronic Compact Fluorescent Ballast, CFL Lamp, 40 W Lamp, 120 to 277 VAC, Instant, 0.88 Ballast Factor
ICN3TTP40SC35IAdvance Centium® ICN3TTP40SC35I Electronic Compact Fluorescent Ballast, CFL Lamp, 40 W Lamp, 120 to 277 VAC, Instant, 0.88 Ballast Factor

Documents

Short Description

Philips Advance Optanium high efficiency electronic ballasts are engineered to optimize lighting performance and maximize energy savings. These ballasts provide an unparalleled package of features and benefits to support the wide variety of T8 fluorescent lamps out in the market place.

Features

  • High power factor

Specification

Minimum Order Qty
1
Order Interval
1
Voltage Rating
120 to 277 VAC
Standard & Approvals
UL Listed, CSA Certified, RoHS Compliant
Number of Lamps
3
Frequency Rating
50/60 Hz
Total Harmonic Distortion
0.1
Start Type
Programmed
Ballast Factor
0.88
Catalog ID
ADVIOP3PSP32SC35I
Dimensions
9.5 in L x 1.7 in W x 1.18 in H
Temperature Range
70 deg C
Application
Outdoor Use
Power Factor
0.98
Enclosure Type
NEMA 27
Amperage Rating
0.31 to 0.71 A
Material
Metal
Lamp Wattage
32 W
Lamp Type
T8
