Advance LC1420CI Electromagnetic Fluorescent Ballast, T12 Lamp, 20 W Lamp, 120 VAC, Pre-Heat, 0.93 Ballast Factor

Selected Advance LC1420CI Electromagnetic Fluorescent Ballast, T12 Lamp, 20 W Lamp, 120 VAC, Pre-Heat, 0.93 Ballast Factor
Advance LC1420CI Electromagnetic Fluorescent Ballast, T12 Lamp, 20 W Lamp, 120 VAC, Pre-Heat, 0.93 Ballast Factor

Features

  • Series lamp connection
  • 112 - 127 VAC Applied voltage limits
  • Yellow color label identification
  • 20 - 24 dB Average ambient noise level
  • High power factor
  • Available for many fluorescent lamp types sold today, including Preheat, Rapid Start, 2-pin CFL, Slimline, High Output, Very High Output and Circline
  • Only choice for many low volume lamp types on the market
  • 60 Hz lamp operation eliminates possible EMI/RFI interference

Specification

Frequency Rating
60 Hz
Lamp Wattage
20 W
Material
Metal
Number of Lamps
1
Minimum Order Qty
1
Order Interval
1
Amperage Rating
0.33 A
Start Type
Preheat
Total Harmonic Distortion
0.1
Voltage Rating
120 VAC
Standard & Approvals
UL File No. E14927, CSA File No. 007310, ANSI C82.1, RoHS Compliant
Minimum Starting Temperature
50 deg F
Series
Standard
Power Factor
0.52
Dimensions
3.06 in L x 1.81 in W x 1.59 in H
Catalog ID
ADVLC1420CI
Ballast Factor
0.9
