Siemens 52SB2CDBA1 Command/Class 52 Non-Illuminated Round Selector Switch, 30 mm, 1NC-1NO Contact, Key Operator

Siemens 52SB2CDBA1 Command/Class 52 Non-Illuminated Round Selector Switch, 30 mm, 1NC-1NO Contact, Key Operator
SKU: SIE52SB2CDBA1
Manufacturer Part Number: 52SB2CDBA1
UPC: 783087156678
Documents
Features
- Water/oil tight and corrosion resistant
- Positively driven contacts
- Positive indexing selectors
- Bifurcated movable contacts
- Without insert
Specification
Material | Plastic |
---|---|
Number of Positions | 3 |
Operator Type | Key |
Minimum Order Qty | 1 |
Order Interval | 1 |
Actuator | Long Lever |
Bezel/Housing | Metal |
Cam Code | C |
Catalog ID | SIE52SB2CDBA1 |
Contact Configuration | 1NC-1NO |
Contact Mode | Spring Return Left and Right |
Enclosure Type | IP20/IP66 |
Environmental Conditions | -35 to 70 deg C Operation/-45 to 85 deg C Storage |
Finish | Polished Chrome |
Series | Command/Class 52 |
Size | 30 mm |
Terminal Type | Screw |
Type | Non-Illuminated Round |
Standard & Approvals | CSA LR6535, NEMA A600/P600, UL E22655 in Vol 6 (7) Sec. 13 (2) |
Includes | Octagonal Mounting Nuts |
