Siemens NGB3B060B Type NGB Low Voltage Molded Case Circuit Breaker, 600Y/347 VAC, 60 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Siemens NGB3B060B Type NGB Low Voltage Molded Case Circuit Breaker, 600Y/347 VAC, 60 A, 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKU: SIENGB3B060B
Manufacturer Part Number: NGB3B060B
UPC: 783643414334
Features
- 1/0 to 6 AWG copper, 2/0 to 4 AWG aluminum wire range
- 14 kA at 600Y/347 VAC, 10 kA at 240 VAC interrupt rating
- Bulk pack
Specification
| Frequency Rating | 50/60 Hz |
|---|---|
| Interrupt Rating | 14 kA |
| Mounting Type | Panel |
| Number Of Poles | 3 |
| Phase | 3 |
| Trip Type | Thermal Magnetic |
| Standard & Approvals | ARRA Compliant, Buy American Act Compliant, RoHS Compliant, HACR Rated, IEC Certified, UL Listed |
| Amperage Rating | 60 A |
| Voltage Rating | 600Y/347 VAC |
| Type | Type NGB Low Voltage |
| Connection Type | Load Lug |
| Dimensions | 6.9 in L x 4 in W x 4.7 in H |
| Wire Size | 4 to 2/0 AWG, 6 to 1/0 AWG |
