***CLEARANCE*** Universal™ ULTim8® B432IUNVHE-A010C Electronic Fluorescent Ballast, T8 Lamp, 32 W Lamp, 120 to 277 VAC, Instant, 0.87 Ballast Factor

Selected ***CLEARANCE*** Universal™ ULTim8® B432IUNVHE-A010C Electronic Fluorescent Ballast, T8 Lamp, 32 W Lamp, 120 to 277 VAC, Instant, 0.87 Ballast Factor
***CLEARANCE*** Universal™ ULTim8® B432IUNVHE-A010C Electronic Fluorescent Ballast, T8 Lamp, 32 W Lamp, 120 to 277 VAC, Instant, 0.87 Ballast Factor

Short Description

For more than 30 years, the lighting industry has relied on our TRIAD® brand for the most specified, most installed, most reliable electronic ballasts in the business. The TRIAD® line offers advantages like installer-friendly universal input voltage, which ensures that you have the right voltage ballast every time, and maximum energy savings for long cycle operations. And our ULTim8® and AccuStart™ ballasts feature high efficiency designs and programmed start technology that dramatically enhances lamp life.

Features

  • Parallel lamp operation
  • NEMA 1 outdoor enclosure

Specification

Frequency Rating
50/60 Hz
Lamp Type
T8
Lamp Wattage
32 W
Minimum Starting Temperature
-18 deg C
Number of Lamps
4
Power Factor
>0.87
Start Type
Instant
Temperature Range
105 deg F
Total Harmonic Distortion
<10%
Voltage Rating
120 to 277 VAC
Wattage
106/109 W
Amperage Rating
0.91 A
Dimensions
9.5 in L x 1.7 in W x 1.18 in H
Clearance
YES
Dimmable
No
Enclosure Type
NEMA 1
Ballast Factor
0.87
