EATON HMCPE050K2C G Series Type HMCP Motor Circuit Protector, 600Y/347/480 VAC, 50 A, 3 Poles, Adjustable Magnetic Trip
EATON HMCPE050K2C G Series Type HMCP Motor Circuit Protector, 600Y/347/480 VAC, 50 A, 3 Poles, Adjustable Magnetic Trip
SKU: C-HHMCPE050K2C
Manufacturer Part Number: HMCPE050K2C
UPC: 786679113677
Documents
Features
- NEMA 2 starter
- 11.5 to 43.5 A motor full load current amperes
- A to F cam setting
- Steel terminal
Specification
| Frame | EG |
|---|---|
| Number Of Poles | 3 |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Video | https://www.youtube.com/watch?v=PY52j05p7to |
| Amperage Rating | 50 A |
| Catalog ID | C-HHMCPE050K2C |
| Dimensions | 6-1/2 in L x 3 in W x 5-1/2 in H |
| Enclosure Type | NEMA 2 |
| Series | Series G |
| Trip Range | 50 to 500 A |
| Trip Type | Adjustable/Magnetic |
| Voltage Rating | 600Y/347/480 VAC |
| Standard & Approvals | UL 489, CE Certified, CSA C22.2 No. 5.1, IEC 157-1 |
