GE 9T58K0044 Encapsulated Type IP Control Transformer, 480 VAC Primary, 115 VAC Secondary, 0.1 kVA, 60 Hz, 1 Phase

Selected 9T58K0047GE 9T58K0044 Encapsulated Type IP Control Transformer, 480 VAC Primary, 115 VAC Secondary, 0.1 kVA, 60 Hz, 1 Phase
9T58K0047GE 9T58K0044 Encapsulated Type IP Control Transformer, 480 VAC Primary, 115 VAC Secondary, 0.1 kVA, 60 Hz, 1 Phase

Documents

Short Description

Core and coil transformers for machine tools are used to provide voltage to control devices in applications where regulation and minimum space are important. Welded cores provide the highest quality electrical performance and quiet operation.

Features

  • Fully encapsulated coil is impervious to moisture
  • Finger-safe terminals offer added protection and safety
  • Pressure plate terminals ensure secure connections
  • Terminal board is anchored in the epoxy for greater reliability
  • Wide variety of fusing options
  • Rugged, high impact plastic terminal board
  • Full head NO 8 brass screws assure quick, easy terminations with maximum connection integrity
  • Flexible design allows input or output voltage to match any application
  • 40 deg C ambient temperature, 55 deg C temperature rise
  • K1 K factor
  • Copper winding
  • Dry type encapsulated
  • 240 x 480 VAC primary voltage
  • Class A insulation

Specification

Frequency Rating
60 Hz
Phase
1
Power Rating
0.1 kVA
Secondary Voltage
115 VAC
Temperature Rating
105 deg C
Type
Encapsulated Type IP
Application
For machine tool applications are used to provide voltage to control devices in applications where regulation and minimum space are important
Standard & Approvals
UL 5085, UL File No. E2739, CSA C22.2 No.6, CSA File No. 3272, NEMA ST20
Circuit Type
8100 Frame
Enclosure Type
Open
Connection Type
Terminal Board
Dimensions
3.3 in H x 3.8 in W x 4.1 in D
Primary Voltage
480 VAC
