ILSCO® SureCrimp® CTL-500 CTL Long Barrel Compression Sleeve, 500 kcmil Copper Conductor, Die Code: I-87, 4-5/8 in L, Copper
ILSCO® SureCrimp® CTL-500 CTL Long Barrel Compression Sleeve, 500 kcmil Copper Conductor, Die Code: I-87, 4-5/8 in L, Copper
SKU: ILSCTL-500
Manufacturer Part Number: CTL-500
UPC: 783669148985
Documents
Features
- Manufactured from high strength seamless copper tubing and electro-tin plated
- Long with chamfered barrel entry, center wire stop
- Proper high voltage spacings and insulation techniques are used, may be used for high voltage applications up to 35 kV
- Copper class B concentric/compressed, class C concentric strand configurations
- Listed with Ilsco tools ILC-12, ILC-12H, ILCB-12, ILC-14, ILC-14H, ILC-15, MT-25, 94285, IDT-12, IDT-12H, ILC-10, IDTB-12
- Provides low contact resistance, maximum conductivity and excellent crimping characteristics and versatility
- Provides easy conductor insertion and insures maximum cable insertion
- Color code identifies the proper compression die
- Expanded wire size with ILSCO dieless tools and Burndy Y644M dieless tool
- Reduces inventory requirements
- 350 kcmil G, H, I, K, M flex 373.7 DLO alternate wire size
- 500 - 250 kcmil expanded wire range
- 6/Pack
Specification
| Length | 4-5/8 in |
|---|---|
| Material | Copper |
| Series | CTL |
| Temperature Rating | 90 deg C |
| Voltage Rating | 600 VAC |
| Dimensions | 0.828 in ID x 1.062 in OD |
| Color | Brown |
| Conductor Type | Copper |
| Connector Type | Crimp |
| Finish | Electro-Tin Plated |
| Die Code | I-87 |
| Conductor Size | 500 kcmil |
| Standard & Approvals | LR-29601 CSA Certified, NEBS Level 3, RoHS Compliant, UL 486A-B, UL E6207 453G Listed |
| Application | For Grounding and Bonding Applications and Splicer/Reducer |
| Type | Long Barrel |
| Specifications | 2-3/8 in L Strip, 0.828 in ID x 1.062 in OD |
