nVent ERICO CADWELD® SST1T Type SS Weld Metal Mold, 2 AWG Solid Conductor, Cable to Cable Connection, Graphite

Selected SST1TnVent ERICO CADWELD® SST1T Type SS Weld Metal Mold, 2 AWG Solid Conductor, Cable to Cable Connection, Graphite
SST1TnVent ERICO CADWELD® SST1T Type SS Weld Metal Mold, 2 AWG Solid Conductor, Cable to Cable Connection, Graphite

Documents

Short Description

nVent ERICO CADWELD® graphite molds are designed and engineered for thousands of connection styles and conductor combinations.

Features

  • Forms a permanent, low resistance connection
  • Provides a molecular bond
  • nVent ERICO CADWELD® exothermic connections are rated with the same current capacity as the conductor
  • Portable installation equipment with no external source of power required
  • Installers can be easily trained to make nVent ERICO CADWELD® exothermic connections
  • Connections can be visually inspected

Specification

Handle Clamp
Mini EZ Attached
Mold Price Key
T
Standard & Approvals
cULus Listed, ANSI/UL 467, UL File No. KDER.E220029, cUL File No. KDER7.E220029, CSA C22.2 File No. 41
Material
Graphite
Connection Type
Cable to Cable
Conductor Size
2 AWG Solid
Application
Facility Electrical Protection, Lightning Protection, Solar Power, Telecom, Utility and Wind Power Applications
Type
Type SS
Specifications
0.257 in OD Conductor, Horizontal Splice
