3M™ Temflex™ 1700P General Grade Vinyl Tape, 66 ft L x 3/4 in W x 7 mil THK, Vinyl, Black

Selected Files3 M1700P3 4X66FT
Files3 M1700P3 4X66FT

Documents

Short Description

3M™ Temflex™ Electrical Tape 1700 is a good quality, economical general purpose vinyl insulating tape. It has excellent resistance to abrasion, moisture, alkalies, acid, copper corrosion and varying weather conditions. It is a polyvinyl chloride (PVC) tape that is flame-retardant and conformable. Temflex™ Tape 1700 provides excellent mechanical protection with minimum bulk.

Features

  • Primary electrical insulation for most wire and cable splices rated up to 600 volts
  • Protective jacketing for high voltage cable splices and repairs
  • Harnessing of wires and cables
  • General purpose vinyl insulating tape
  • Resistance to abrasion, moisture, alkalies, acid, copper corrosion and varying weather conditions
  • Polyvinyl chloride (PVC) tape that is flame-retardant and conformable
  • Mechanical protection with minimum bulk

Specification

Length
66 ft
Material
Vinyl
Voltage Rating
600 VAC
Color
Black
Shape
Roll
Thickness
7 mil
Tensile Strength
17 in-lb
Temperature Rating
32 to 176 deg F
Standard & Approvals
UL 510, File NO. E129200, CSA C22.2 No. 197-M1983 File No. LR48769, RoHS 2002/95/EC Compliant, ASTM D 2301 Type 1,¿ MSHA Approved
Dielectric Strength
>1000 V/mil
Backing Material
PVC
Application
Indoor or Outdoor, Above or Below Ground Applications
Adhesive Material
Rubber
Adhesion Strength
22 in-oz
