Advance Xitanium Intellivolt LEDINTA0700C210DOM Constant Current LED Driver, 120 to 277 VAC Input, 210 VDC Output, 165 W Power Rating, 8.38 in L x 2.35 in W

Selected LEDINTA0700C210DOMAdvance Xitanium Intellivolt LEDINTA0700C210DOM Constant Current LED Driver, 120 to 277 VAC Input, 210 VDC Output, 165 W Power Rating, 8.38 in L x 2.35 in W
LEDINTA0700C210DOMAdvance Xitanium Intellivolt LEDINTA0700C210DOM Constant Current LED Driver, 120 to 277 VAC Input, 210 VDC Output, 165 W Power Rating, 8.38 in L x 2.35 in W

Documents

Short Description

These drivers are available in wattages of 40W to 150W for hard-wired integration into outdoor luminaires for the most rugged applications. They operate to specification under wide temperature and electrical ranges to ensure reliability.

Features

  • 150 W Output power
  • 0.7 A Output current
  • 20% THD

Specification

Standard & Approvals
UL Listed, CSA Certified, RoHS Compliant
Power Factor
0.9
Power Rating
165 W
Temperature Rating
-40 deg C
Amperage Rating
0.6 to 1.4 A
Input Voltage
120 to 277 VAC
Output Voltage
210 VDC
Type
Constant Current
Length
8.38 in
Height
1.47 in
Width
2.35 in
