Allen-Bradley 100-C09UEJ10 Contactor, 9 A, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open poles, 24V DC Electronic, 1 NO Contacts & 0 NC Contacts, Single Pack, Load Side Coil Termination, Screw Terminals, Motor Load
Allen-Bradley 100-C09UEJ10 Contactor, 9 A, 24V50/60Hz/24VDC Elec Cl, Electronic, 3 Normally Open poles, 24V DC Electronic, 1 NO Contacts & 0 NC Contacts, Single Pack, Load Side Coil Termination, Screw Terminals, Motor Load
SKU: A-B100C09UEJ10
Manufacturer Part Number: 100-C09UEJ10
UPC: 612598642953
Documents
Specification
| Package Quantity | 1 |
|---|---|
| Rated Operating Current, AC-3 | 9A |
| 1-Phase HP (60 Hz) 115V Rating | 0.5 |
| 1-Phase HP (60 Hz) 230V Rating | 1.5 |
| 3-Phase HP (60 Hz) 200V Rating | 2 |
| 3-Phase HP (60 Hz) 230V Rating | 2 |
| 3-Phase HP (60 Hz) 460V Rating | 5 |
| 3-Phase HP (60 Hz) 575V Rating | 7.5 |
| 3-Phase kW (50 Hz) 230V Rating | 3 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 4 |
| 3-Phase kW (50 Hz) 500V Rating | 4 |
| 3-Phase kW (50 Hz) 690V Rating | 4 |
| Connection | Screw Terminals |
| Contact Configuration | 1 N.O. 0 N.C. Auxiliary Contact Configuration |
| Coil Voltage | 24V DC Electronic Coil w/ Elec. Interface |
| Coil Termination | Load Side |
