Allen-Bradley, 100-C23L10, 100-C IEC Contactor, 208-240V 60Hz, Screw Terminals, Line Side, 23A, 1 N.O. 0 N.C. Auxiliary Contact Configuration
Allen-Bradley, 100-C23L10, 100-C IEC Contactor, 208-240V 60Hz, Screw Terminals, Line Side, 23A, 1 N.O. 0 N.C. Auxiliary Contact Configuration
SKU: A-B100C23L10
Manufacturer Part Number: 100-C23L10
UPC: 662072596074
Documents
Specification
| Minimum Order Qty | 1 |
|---|---|
| Order Interval | 1 |
| 1-Phase HP (60 Hz) 230V Rating | 3 |
| 3-Phase HP (60 Hz) 200V Rating | 5 |
| 3-Phase HP (60 Hz) 230V Rating | 7.5 |
| 3-Phase HP (60 Hz) 460V Rating | 15 |
| 3-Phase HP (60 Hz) 575V Rating | 15 |
| 3-Phase kW (50 Hz) 230V Rating | 7.5 |
| 3-Phase kW (50 Hz) 400V/415V Rating | 11 |
| 3-Phase kW (50 Hz) 500V Rating | 13 |
| 3-Phase kW (50 Hz) 690V Rating | 10 |
| Catalog ID | A-B100C23L10 |
| Coil Termination | Line Side |
| Coil Voltage | 200-220V 50Hz / 208-240V 60Hz |
| Connection | Screw Terminals |
| Contact Configuration | 1 N.O. 0 N.C. Auxiliary Contact Configuration |
| Package Quantity | 1 |
| Rated Operating Current, AC-3 | 23A |
