Allen-Bradley 140G-G2C3-C63 Molded Case Circuit Breaker, G frame, 25 kA at 480V, T/M - Fixed Thermal / Fixed Magnetic TMF, Rated Current 63 A, InterruptingCode G2
Allen-Bradley 140G-G2C3-C63 Molded Case Circuit Breaker, G frame, 25 kA at 480V, T/M - Fixed Thermal / Fixed Magnetic TMF, Rated Current 63 A, InterruptingCode G2
SKU: A-B140GG2C3C63
Manufacturer Part Number: 140G-G2C3-C63
UPC: 885630446936
Specification
| Frame/Rating | G Frame (125 A) |
|---|---|
| Interrupting Rating, 50/60 Hz, 240V (kA) | 50 |
| Interrupting Rating, 50/60 Hz, 480V (kA) | 25 |
| Interrupting Rating, 50/60 Hz, 600V (kA) | 10 |
| Number Of Poles | 3 Poles |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Breaking Capacity, 50/60 Hz, 220V (kA) | 65 |
| Breaking Capacity, 50/60 Hz, 415V (kA) | 36 |
| Breaking Capacity, 50/60 Hz, 440V (kA) | 36 |
| Breaking Capacity, 50/60 Hz, 690V (kA) | 6 |
| Bulletin Number | 140G - Molded Case Circuit Breaker |
| Catalog ID | A-B140GG2C3C63 |
| Protection | T/M - Thermal Magnetic |
