Allen-Bradley 1734-IE8C Current Input Module, POINT I/O, Analog, 24V Dc, 8 Channels, Open Style, DINMounted
Allen-Bradley 1734-IE8C Current Input Module, POINT I/O, Analog, 24V Dc, 8 Channels, Open Style, DINMounted
SKU: A-B1734IE8C
Manufacturer Part Number: 1734-IE8C
UPC: 612598347872
Specification
| Input | 8 Point |
|---|---|
| Isolation Voltage | 50V (continuous), basic insulation type, inputs and field power to system. Type tested at 1500V AC for 60 s. No isolation between individual inputs or inputs to field power |
| Mounting | Din-rail |
| PowerSupply | 24V DC |
| Special Features | Standard |
| Sub Brand | POINT |
| Temperature Rating | -20...55 °C (-4...131 °F) |
| Type | Analog Input Module |
| Application | In-Cabinet |
| Enclosure | None (open-style) |
| Signal Range | 4...20mA, 0...20mA |
| Resolution | 16 Bits |
