Allen-Bradley, 1769-IF16C, 16 Channel Compact High- density Analog Current Input Module
Allen-Bradley, 1769-IF16C, 16 Channel Compact High- density Analog Current Input Module
SKU: A-B1769IF16C
Manufacturer Part Number: 1769-IF16C
UPC: 612598626786
Specification
| Height | 4.65 in |
|---|---|
| Input Signal | 0...20 mA, 4...20 mA |
| Isolation | 500V AC or 710V DC for 1 min (qualification test), output group to bus. 30V AC/30V DC working voltage (IEC Class 2 reinforced insulation) |
| Number of Channels | 16 |
| Operating Temperature | 0...60 °C (32...140 °F) |
| Minimum Order Qty | 1 |
| Order Interval | 1 |
| Catalog ID | A-B1769IF16C |
| Depth | 87mm, 3.43" |
| Display | Status LEDs |
| Enclosure | None (open-style) |
| Type | Analog Input Module |
| Width | 1.38 in |
| Mounting | DIN Rail / Panel Mount |
